Product Details
T/F 40 - Auxiliary conveyors
Auxiliary conveyorsTechnical Data
- Electro-welded sheet iron structure.
- Feedbox in electro-welding execution.
- Support base to be fixed on worktable with inclination from 0° to 30°.
- With stand 550 high, at 0° the discharge throat and height at 330. At 30° the discharge throat and height at 660.
- Dragging rollers an tensioning device diametre 40.
- Speed 1,2 m/min.
- Voltage 380 V 50 Hz 3-Phase.
On request
- D.C. motor for adjustable speed (220 V 50 Hz Single-Phase).
- Speeds different from the standard ones.
- Voltage 220 V 50 Hz Single Phase.
- Vullkolan scrapers.
Category: Elevators
