Product Details
GR/70 Inox - Conveyors
Grecati belt conveyorsTechnical Data
- Electric connection: 220/380V 50Hz 3-Phase.
- Standard speed: 3,8 m/min.
- Lower speeds on request.
- INOX AISI 304 steel belt type "GRECATO" pitch 13,7 mm.
- Carbon steel pinions type Z16 PD 70,22 mm. (other diematers sizes on request).
- Electro-welded sheet iron structure.
- Height of side walls: 50 mm. Included in the structure.
- Different heights of the side walls on request.
- Inferior motor drive with lateral chain drive.
- Gear reducer type I50FP 80/1 + motore of 0.37Kw.
- Ideal to feed pieces which reach temperature up to 500°C.
On request
- Bases with fixed or adjustable height.
- Electrical equipment with startand emergency button.
