EX/38.M - Elevator with light metal plaques
Elevator with light metal plaquesTechnical Data
- Electric connection 220/380V 50Hz 3-Phase.
- Electro-welded sheet iron structure.
- Steel belt at fastened plaques.
- Driving and tightener pinions in steel.
- Fixed inclination of about 23°.
- Gear reducer type I60 FBR 1/100 and motor of 0,37 Kw.
- Standard speed of about 5 m/min.
- With lower protection of the metal belt.
- Base.
On request
- Electric control board.
- Upper protection of the side walls.
- Bases on wheels.
- Different sizes from the standard ones.
