Arnaboldi Italia

E/G 120 - Elevators in PVC

• Electro-welded sheet iron structure.
• Feedbox, side walls, discharge throat in electro-welding execution.
• Electro-welded support base with adjustable feet.
• Dragging rollers and tensioning device diametre 100.
• Side motor placed in the upper part.
• Tensioning device in the lower part.
• Rubber scraping bulkhead in the lower part of the feed box.
• Inclination of 60°.
• Smooth PVC belt with hot applied cross splines.
• Speed 5,5 m/min.
• Voltage 380 V 50 Hz 3 Phase
•

• On request
• Inverter for speed adjustment.
• Voltage 220 V 50 Hz Single Phase.
• Speeds different from the standard ones.
• Side walls, feedbox and discharge throat covering in plastic material.
• Upper covering of side walls and discharge throat in transparent PVC.
• Feedbox upper covering (can be opened) in transparent PVC.
