Product Details
CL 100/P - CL 100/M - Trasportatore
Conveyor with large silent chainTechnical Data
- Electric connection 220/380V 50Hz 3-Phase.
- Standard speed: 9 m/min.
- Electro-welded sheet iron structure.
- Silent chain type 1/2".
- Straight-tooth gears in carbon steel.
- Gear reducer type I50 and motor of 0,37 Kw.
Series CL 100/P
- Sliding of the chain on Polizene.
Series CL 100/M
- Sliding of the chain on steel.
- Fit to convey hot pieces.
On request
- Electric control board.
- Bases.
- Side walls.
- Different measures from the standard ones.
