Product Details
GR/TT 1 - Transversal module
Transversal module with central dragging for movement of palletsTechnical Data
- Electric connection 220/380V 50Hz 3-Phase.
- Aluminium structural shape frame 45x45 mm.
- Width of the belt 40 mm.
- Top rollers Ø 50 mm.
- Dragging group and tensioning device placed in the center.
- Standard speed of the belt of about 12 m/min.
- Power of 0,18 Kw.
- Bases in electro-welded structure placed at center distance of 1200 mm.
- Length suggested: max. 1500 mm.
- Not fit for application of retainers or work station.
On request
- Bases in aluminium shape frame.
- Different sizes from the standard ones.
