FX/38.LPP FX/38.LPM FX/38.LM - Conveyor

Slat conveyor

Technical Data
  • Electric connection: 220/380V 50Hz 3-Phase.
  • Electro-welded sheet iron structure.
  • With back plugging of the side walls.

Series FX/38.LPP
  • Belt at fastened plaques in acetalic.
  • Sliding of the belt on Polizene.
  • Driving and tightener pinions in polyamide.

Series FX/38.LPM
  • Steel belt at fastened plaques (max. width 190,5 mm.).
  • Sliding of the belt on Polizene.
  • Driving and tightener pinions in polyamide.

Series FX/38.LM
  • Steel belt at fastened plaques (max. width 190,5 mm.).
  • Sliding of the belt on steel.
  • Fit to convey heated pieces (until 300°C).
  • Driving and tightener pinions in steel.

On request
  • Electric control board.
  • Bases.
Category: Slat conveyors
